Color Force 72™

The Chroma-Q® Color Force™ LED batten range is a brute of a light. The super bright fixture easily washes up to 8m / 26 ft. In addition, the RGBA LED engines provide a radically increased colour palette, together with a high CRI of 92 and theatrical grade dimming, all in the same fixture.

Request A Demo

Mighty Output
The Color Force offers extreme light output, lighting an 8m / 26ft drop cyclorama in your choice of colour. Optional accessories include a Cyc lens plate for up to 5m / 20ft drop and a Border lens plate for general purpose wash applications. Below demonstrates the Color Force output compared to a traditional 1kW cyc flood. Identical camera settings were used in the comparative photos.

Power across the Spectrum
The Color Force offers massive output across the spectrum, ensuring both vivid saturates and subtle palette colours are available from a single fixture. It provides a single fixture solution for concert touring, corporate events, exhibitions, TV and theatre. The Chroma-Q RGBA engine has been developed to deliver an incredible CRI of 92, for true colour balance across the spectrum.

Optics
The Color Force custom optical design provides a smooth, uniform output with outstanding smooth colour blend across the spectrum.

Practical & Mechanical
On the outside, the Color Force has been designed to provide maximum versatility and ease of use. The built-in power supply, hidden quick release fixings requiring no tools, and mains power / DMX in at one end and out the other provide fast deployment and simple cable management. The Color Force also features stand-alone Master and Slave modes for additional usage possibilities, flat end plates for seamless wall-washing and a rugged extruded aluminium body.

Control
The Color Force features smooth, theatrical grade dimming and intuitive colour control for all console types. Advanced software enables industry standard 3 channel RGB and HSI control for each light engine. A full range of flicker-free modes are also included.

Effects
With separate RGBA control every 150mm / 6” and a comprehensive built-in effects engine, the Color Force offers new possibilities in cyclorama effects.

Product Code CHCF72NFRGBA
Net Dimensions 1,759mm x 182mm x 177mm / 69.25” x 7.25” x 7”
Net Weight 22kgs / 48lbs
Power Input Rating 100-240V AC, 50-60 Hz, 700VA
Control Protocol ANSI E1.11 USITT DMX 512-A
Cooling System Forced - 2x fans
Construction Anodised aluminium extrusion
Built-In Hardware Quick release lever for tilt adjustment
IP Rating IP20
Approvals CISPR 22 :2006/EN55022 :2006 & CISPR 24 :1997/ EN55024 :1998, ICES-003 :2004 & FCC Part 15 Subpart B: 2007, CSA C22. No. 166-M1983:R2008 UL 1573:2003; UL 8750
LEDs 12 LED engines, 24 (6 x RGBA) LEDs, 288 total LEDs
Control Modes 43 channels Fx HSI
36 channels HSI
36 channels RGB (*Magic Amber)
48 channels RGBA
49 channels sRGBI (*Magic Amber)
9 channels Fx HSI
3 channels HSI
3 channels RGB
4 channels RGBA
5 channels sRGBI (*Magic Amber)
1 channel DMX Look Select
Dimming Curve Theatrical
Variable Effects Engine Yes
Lumen Output White 8,000 / 12,000 hot lumens (prelim.)
Optics Specialised close focus lens
Beam Angle 23° (approx.)
Beam Distribution Asymmetrical direct illumination
CCT Adjustable 1,000 - 10,000K
CRI 92
Colour Gamut Performance enhanced
Lamp Life L70 at 50,000 hours
