Studio Force D XT 12™

Utilising the same core technologies as the innovative Chroma-Q® Studio Force D 12™ daylight white LED fixture, the Studio Force D XT 12 is an ultra bright, higher-output version that provides a blistering 15,000 lumens output. Specifically designed for TV, film, touring, exhibitions, corporate events and theatre lighting applications, the Studio Force D XT 12™ is perfect for evenly washing large areas, complemented by its smooth, theatrical grade dimming. At only 335mm / 1ft* long, the unit is ideal for floor, wall, stand or truss mounting.

*Measurements may have been rounded, please see specification sheet for full measurements.

Key Features

  • 6,100K CCT (+/-200k) daylight white
  • Extreme output – up to 15,000 lumens
  • Extremely smooth, uniform wash
  • Theatrical grade dimming
  • Ideal for TV, film, touring, exhibitions, corporate events and theatre
  • 335mm / 13.2" length ideal for floor, wall or truss mounting
  • Camera friendly
  • PowerCon input and output for easy daisy chaining of fixtures
  • Broad range of accessories available, including lightbank kit and barn door
  • Flat end plates for seamless wall-washing
  • Built-in power supply
  • Hidden quick release fixings
  • Rugged extruded aluminium body

Request A Demo

Over 50% More Output
Utilising the very latest generation of LED and optics, the Studio Force D XT 12 offers an extreme output of 15,000 lumens - over 50% brighter than the original Studio Force D 12™ (6,000 lumens)

Multi-purpose
The Studio Force D XT 12™ is suitable for a wide range of lighting applications, including key-lighting, uplighting, backlighting and wash applications.

Colour
The Studio Force D XT 12™ includes ColorSure™ technology for enhanced consistency across each light engine and when using multiple fixtures.

Optics & Dimming
The Studio Force D range's camera friendly custom optical design provides a smooth, uniform output, matched by theatrical grade dimming.

Practical & Mechanical
Featuring a camera friendly custom optical design, the Studio Force D XT 12™ provides a smooth, uniform output, matched by theatrical grade dimmimg.

On the outside, the Studio Force D XT 12™ has been designed to provide maximum versatility and ease of use. The built-in power supply, hidden quick release fixings requiring no tools, and PowerCon and 5-pin DMX connections in and out provide fast deployment and simple cable management.

The Studio Force D range also features stand-alone Master and Slave modes for additional usage possibilities, flat end plates for seamless wall-washing and a rugged extruded aluminium body.

Product Code CHSFDXT12N
Dimensions** 335mm x 190mm x 218mm / 13.2" x 7.5" x 8.6"
Weight 4kgs / 9lbs
Shipping Dimensions 432mm x 343mm x 279mm / 17" x 13.5" x 11"
Shipping Weight 6kgs / 13lbs
Power Supply Built-in
Power Input Rating 100-240V AC, 50-60 Hz, 160VA
Power Factor 0.997
Power Consumption 170W
Typical Power & Current Measurements done with all LEDs at max. intensity. Measurements made at nominal voltage. Allow for a deviation of +/- 10%
Power Connector In/Out PowerCon
Data Connectors In/Out XLR 5-pin
Control Protocol ANSI E1.11 USITT DMX 512-A
Cooling System Forced - 1 fan
Operating Temperature 0°C to 40°C
Construction Anodised aluminium extrusion
Colour Black
Built-In Hardware Quick release lever for tilt adjustment
IP Rating IP20
Approvals CISPR 22 :2006/EN55022 :2006 & CISPR 24 :1997/EN55024 :1998, ICES-003 :2004& FCC Part 15 Subpart B: 2007
LED Engines 2
LEDs Per Engine 24 Cold White
Total LEDs 48
Control Modes 8 channels Dim8x
2 channels FxDim
2 channels Dim2x
1 channel Dim1x
1 channel Look Select
Master Standalone
Slave Standalone
Manual
Dimming Curve Theatrical
Variable Effects Engine Yes
Effects Parameters Intensity Effects
Hot Lumen Output Up to 15,000
Optics Specialised close focus lens
Beam Angle ~17°
Beam Distribution Symmetrical direct illumination
CCT 6,100K (+/- 200K)
Colour Gamut Performance enhanced
CRI >70
Lamp Life L70 at 50,000 hours
