Color Block Plus™ Replacement Engine for DB4

The Color Bloc Plus™ Replacement Engine for the Chroma-Q® Color Block™ DB4 enables rental companies and other users to gain an even greater return on their investment in this still widely used fixture.

Key Features

  • Color Block DB4 emulation mode
  • More cost-effective than replacing whole fixture
  • Eco-friendly solution
  • Compatible with all Color Block / Color Block 2 power supplies and accessories

Request A Demo

Please note this item was discontinued in March of 2015

Cost Effective Alternative
Designed to be fitted by authorised Chroma-Q® service agents, the Color Block Plus™ Replacement Engine provides a cost-effective alternative to replacing the whole Color Block™ DB4 fixture - so it's kind to the environment as well as your budget.

Color Block DB4 Emulation Mode
For maximum convenience, it also features a Color Block DB4 emulation mode, to simulate the lumen output of the original LED engine when used alongside other first generation fixtures.

Product code CH602-0126
LEDs 4 RGB cells, total 12 LEDs
Hot lumen output CB Plus Mode: 600 hot lumens, CB DB4 Mode: 290 hot lumens
Optics Specialised close focus lens
Beam angle 14°
Beam distribution Assymetrical direct illumination
CCT Adjustable 1,000 to 10,000 K
Lamp Life L70 at 50,000 hours
Approvals CE
