Color Force 48™
The Chroma-Q® Color Force™ LED batten range is a brute of a light. The super bright fixture easily washes up to 8m / 26 ft. In addition, the RGBA LED engines provide a radically increased colour palette, together with a high CRI of 92 and theatrical grade dimming, all in the same fixture.Request A Demo
The Color Force offers extreme light output, lighting an 8m / 26ft drop cyclorama in your choice of colour. Optional accessories include a Cyc lens plate for up to 5m / 20ft drop and a Border lens plate for general purpose wash applications. Below demonstrates the Color Force output compared to a traditional 1kW cyc flood. Identical camera settings were used in the comparative photos.
Power across the Spectrum
The Color Force offers massive output across the spectrum, ensuring both vivid saturates and subtle palette colours are available from a single fixture. It provides a single fixture solution for concert touring, corporate events, exhibitions, TV and theatre. The Chroma-Q RGBA engine has been developed to deliver an incredible CRI of 92, for true colour balance across the spectrum.
The Color Force custom optical design provides a smooth, uniform output with outstanding smooth colour blend across the spectrum.
Practical & Mechanical
On the outside, the Color Force has been designed to provide maximum versatility and ease of use. The built-in power supply, hidden quick release fixings requiring no tools, and mains power / DMX in at one end and out the other provide fast deployment and simple cable management. The Color Force also features stand-alone Master and Slave modes for additional usage possibilities, flat end plates for seamless wall-washing and a rugged extruded aluminium body.
The Color Force features smooth, theatrical grade dimming and intuitive colour control for all console types. Advanced software enables industry standard 3 channel RGB and HSI control for each light engine. A full range of flicker-free modes are also included.
With separate RGBA control every 150mm / 6” and a comprehensive built-in effects engine, the Color Force offers new possibilities in cyclorama effects.
- Color Force 48™ Brochure
- Color Force 48™ Spec Sheet
- Color Force 48™ User Manual
- Color Force 48™ Quick Start Guide
- Color Force 48™ Software v2.2
- Color Force 48™ Software Module v2.1
- Color Force 48™ Exploded Diagram
- Color Force 48™ IES
- Color Force 48™ CAD Symbol
- Color Force 48™ Declaration of Conformity
- Download All
|Net Dimensions||1,181mm x 182mm x 177mm / 46.5” x 7.25” x 7”|
|Net Weight||15kgs / 33lbs|
|Power Input Rating||100-240V AC, 50-60 Hz, 400VA|
|Control Protocol||ANSI E1.11 USITT DMX 512-A|
|Cooling System||Forced - 2x fans|
|Construction||Anodised aluminium extrusion|
|Built-In Hardware||Quick release lever for tilt adjustment|
|Approvals||CISPR 22 :2006/EN55022 :2006 & CISPR 24 :1997/ EN55024 :1998, ICES-003 :2004 & FCC Part 15 Subpart B: 2007, CSA C22. No. 166-M1983:R2008 UL 1573:2003; UL 8750|
|LEDs||8 LED engines, 24 (6 x RGBA) LEDs, 192 total LEDs|
|Control Modes||31 channels Fx HSI
24 channels HSI
24 channels RGB (*Magic Amber)
32 channels RGBA
33 channels sRGBI (*Magic Amber)
9 channels Fx HSI
3 channels HSI
3 channels RGB
4 channels RGBA
5 channels sRGBI (*Magic Amber)
1 channel DMX Look Select
|Variable Effects Engine||Yes|
|Lumen Output||White 8,000 / 12,000 hot lumens (prelim.)|
|Optics||Specialised close focus lens|
|Beam Angle||23° (approx.)|
|Beam Distribution||Asymmetrical direct illumination|
|CCT||Adjustable 1,000 - 10,000K|
|Colour Gamut||Performance enhanced|
|Lamp Life||L70 at 50,000 hours|
