Color Punch™
Please note this item was discontinued in November of 2009
The Chroma-Q® Color Punch™ is extremely powerful for its size, providing lighting designers with a very punchy 1250 lumens output in a compact fixture. Combined with its IP65 rated, tough machined aluminium and high impact plastic casing, this makes the Color Punch suitable for use on even the most demanding lighting applications.
Request A DemoKey Features
- High output (1250 lumens) - for bright washlight results
- IP65 rated
- Choice of RGB, Fx HSI, St RGBI and DMX Look Select control modes
- Built-in power supply and choice of playback looks - no need for additional hardware & cabling
- Supplied with versatile yoke - can be floor standing or hung
- Choice of stand-alone or DMX control - for maximum versatility
- No fans, convection cooled - for completely silent operation
| Product Code | CHCP (22°) / CHCP10 (10°) |   |
|---|---|---|
| A (no fixings) | 213mm / 8.4" | |
| B (no fixings) | 153mm / 6" | |
| Depth (no fixings) | 180mm / 7" | |
| Weight | 3.5kg / 7.7lbs | |
| Power | 90-240V, 50/60Hz, 81W, 1m training lead | |
| Cooling | Convection | |
| Construction | Black anodised aluminium extrusion (white available on special order) | |
| IP rating | IP65 | |
| CE | Pending for EN55103-1 & 2 | |
| Electrical | Pending for IEC60950 | |
| LEDs | 1 x RGB cells, total 36 LEDs |
|---|---|
| Control modes | 3 channel RGB 4 channel Fx HSI 5 channel St RGBI 1 channel stand-alone master Demo 1 channel DMX Look select |
| Effects engine | Yes |
| Hot lumen output | Red: 470 hot lumen, Green: 1100 hot lumen, Blue: 112 hot lumen, White: 1250 hot lumen |
| Optics | Specialised close focus lens with advanced beam spreading technology |
| Beam angle | 22° (optional beam kits available, see Accessories) |
| Beam distribution | Symmetrical direct illumination |
| CCT | Adjustable 1,000-10,000K |
| CRI | 75 |
| Colour gamut | Performance enhanced |
| Lamp life | L70 up to 50,000 hours |
