Studio Force D 72™
Please note this item was discontinued in January 2018
Utilising the same core technologies as the innovative Chroma-Q® Color Force™ LED battens range, the Studio Force™ D 72™ model is a 6,100K CCT, daylight white version specifically designed for TV, film, touring, exhibitions, corporate events and theatre lighting applications. With an extreme output of up to 28,000 lumens, the battens evenly wash large areas, complemented by smooth, theatrical grade dimming.
Key Features
- 6,100K CCT daylight white
- Extreme output - 20,000 lumens (48) / 28,000 lumens (72)
- Extremely smooth uniform wash
- Theatrical grade dimming
- Ideal for TV, film, touring, exhibitions, corporate events and theatre
- PowerCon input and output for easy daisy chaining of fixtures
- Optional cyc and border light lens media accessories
- Hidden quick release fixings
Extreme Output
Available in a choice of 1.2m / 4ft (48) and 1.8m / 6ft (72) batten lengths, the fixtures offer more than twice the white light output of their RGBA colour variants - ranging from 20,000 lumens (48) up to 28,000 lumens (72).
Multi-purpose
The Studio Force D battens are suitable for a wide range of lighting applications, including key-lighting, uplighting, backlighting and wash applications.
Optional accessories include a cyc lens and a border light lens for general purpose wash applications, and a half snoot.
Colour
The Studio Force D range includes ColorSure™ technology for enhanced consistency across each light engine and when using multiple fixtures.
Optics & Dimming
The Studio Force D range's camera friendly custom optical design provides a smooth, uniform output, matched by theatrical grade dimming.
Practical & Mechanical
On the outside, the Studio Force D battens have been designed to provide maximum versatility and ease of use. The built-in power supply, hidden quick release fixings requiring no tools, and PowerCon and 5-pin DMX connections in at one end and out the other provide fast deployment and simple cable management.
The Studio Force D range also features stand-alone Master and Slave modes for additional usage possibilities, flat end plates for seamless wall-washing and a rugged extruded aluminium body.
Studio Force V Range
All three models are also available as Studio Force V 3,000K - 6,100K CCT variable white versions.
| Studio Force D 72 | |
|---|---|
| Product Code | CHSFD72NF |
| Dimensions* | 1,759mm x 182mm x 177mm / 69.25" x 7.25" x 7" |
| Weight | 22kgs / 48lbs |
| Shipping Dimensions | 1,855mm x 305mm x 320mm / 73" x 12" x 12.5" |
| Shipping Weight | 25kgs / 56lbs |
| Power Supply | Built-in |
| Power Input Rating | 100-240V AC, 50-60 Hz, 700VA |
| Power Factor | 0.995 |
| Power Consumption | 660W |
| Typical Power & Current | Measurements done with all LEDs at max. intensity. Measurements made at nominal voltage. Allow for a deviation of +/- 10% |
| Power Connector In/Out | PowerCon |
| Data Connectors In/Out | XLR 5-pin |
| Control Protocol | ANSI E1.11 USITT DMX 512-A |
| Cooling System | Forced - 2 fans |
| Operating Temperature | 0°C to 40°C |
| Construction | Anodised aluminium extrusion |
| Colour | Black |
| Built-In Hardware | Quick release lever for tilt adjustment |
| IP Rating | IP20 |
| Approvals | CISPR 22 :2006/EN55022 :2006 & CISPR 24 :1997/EN55024 :1998, ICES-003 :2004 & FCC Part 15 Subpart B: 2007, CSA C22. No. 166-M1983:R2008 UL 1573:2003; UL 8750 |
| Studio Force D 72 | |
|---|---|
| LED Engines | 12 |
| LEDs Per Engine | 24 Cold White |
| Total LEDs | 288 |
| Control Modes | 48 channels Dim48 2 channels FxDim 12 channels Dim12 1 channel Dim1x 1 channel Look Select Master Standalone Slave Standalone Manual |
| Dimming Curve | Theatrical |
| Variable Effects Engine | Yes |
| Effects Parameters | Intensity Effects |
| Hot Lumen Output | White 28,000 hot lumens |
| Optics | Specialised close focus lens |
| Beam Angle | ~23° |
| Beam Angle with Optional Cyc Optic | 80 x 30° (approx.) |
| Beam Angle with Optional Border Optic | 60° (approx.) |
| Beam Distribution | Asymmetrical direct illumination |
| CCT | 6,100K (+/- 200K) |
| Colour Gamut | Performance enhanced |
| CRI | >70 |
| Lamp Life | L70 at 50,000 hours |
