Color Block™
One Fixture, Endless Solutions
The Chroma-Q® Color Block™ has a modular design and a comprehensive range of fixing options that allows users to easily create a complete LED system using stock of just one generic fixture type - including battens, blinders and various mounting configurations using the built in fixing.
Please note this item was discontinued in November of 2011
Key Features
- All-purpose design
- Modular construction
- Variable Effects Engine
- HSI (Hue, Saturation & Intensity) and RGB control
- Range of fixings
- Efficient thermal management
- Heavy gauge anodised aluminium extrusion
- Slimline design with cable management
- Whisper quiet cooling fan
- PSU with on-board memory
| Product Code | CHCB4: Chroma-Q Color Block DB4 |
|---|---|
| A (no fixings) | 250mm / 9.8" |
| B (no fixings) | 62mm / 2.4" |
| Depth (no fixings): | 117mm / 4.6" |
| Weight | 1.4kg / 3.1lbs |
| Power consumption | HSI = 0.45A @ 48V DC, RGB = 0.9A @ 48V DC |
| Connector | XLR4 |
| Colour | Black anodised |
| Cooling Fans | 2 x DC |
| Lamp life | Up to 25,000 hours |
| IP Rating | IP20 |
| Variable effect engine parameters | Colour spread, scroll, grouping, step, strobe, colour roll, speed, fade (up/down) and resolution |
| Stand-alone | Yes, via built-in software |
| Fixing methods | Built-in M10 socket for stand mount or vertical hanging quick release catch |
| No. of LED heads | 4 x RGB |
|---|---|
| Optics | Specialised close focus lens |
| Source | 12 LEDs each with individual control (4 red, 4 green, 4 blue) |
| Lumen output | Red 112 lumen, Green 150 lumen, Blue 27 lumen, White 283 lumen |
| Beam Angle | 14° (at 50% of peak illuminance) |
| Distribution | Symmetrical direct illumination |
| CCT | Adjustable 1000 - 10,000K |
| CRI | Not measurable |
| Colour gamut | Performance Enhanced |
Photometric Data for Colour White
| 3'/1m | 6'/2m | 9'/3m | 12'/4m | 15'/5m | |
| FC | 276 | 84.5 | 39.6 | 22.1 | 14 |
| Lux | 2970.5 | 909.5 | 425.8 | 238 | 151 |
Photometric Data for Colour Red
| 3'/1m | 6'/2m | 9'/3m | 12'/4m | 15'/5m | |
| FC | 77.9 | 23.8 | 11.2 | 6.2 | 4 |
| Lux | 838.3 | 256.3 | 120.8 | 66.7 | 42.7 |
Photometric Data for Colour Green
| 3'/1m | 6'/2m | 9'/3m | 12'/4m | 15'/5m | |
| FC | 182.4 | 55.5 | 25.8 | 14.4 | 9.2 |
| Lux | 1963.3 | 597.8 | 227.3 | 155 | 98.9 |
Photometric Data for Colour Blue
| 3'/1m | 6'/2m | 9'/3m | 12'/4m | 15'/5m | |
| FC | 28.8 | 9.5 | 4.5 | 2.6 | 1.6 |
| Lux | 310 | 102 | 48.5 | 27.6 | 17.7 |
