Color Block 2™
Redefining LED Lighting
Please note this item was discontinued in September of 2013
Following the enormous success of the Chroma-Q® Color Block™ LED fixture with rental companies and end users alike, we have combined the product's core elements of modularity and versatility with new single colour RGBA optics, 530 lumens output (almost double the original model) and theatrical grade dimming to create the exceptional feature set of the Color Block 2™ fixture.
Key Features
- CRI of 90 - for tungsten emulation
- Enhanced colour range - create subtle theatrical hues
- Single colour diffused optics - virtually eliminate multicoloured shadows & offer camera friendly output
- Exceptional colour brightness & light output levels
- Advanced beam spreading technology - even colour mix across the beam
- Modular construction with range of fixing accessories - easily configured as a wide variety of shapes
| Product Code | CHCB4M2 |  |
|---|---|---|
| A (no fixings) | 250mm / 9.8" | |
| B (no fixings) | 62mm / 2.4" | |
| Depth (no fixings): | 119mm / 4.7" | |
| Weight | 1.3kg / 2.8lbs | |
| Connector | XLR4 in and through | |
| Construction | Black anodised aluminum extrusion | |
| Cooling | Forced air | |
| Built-in hardware | Interlocking system & quick release catches for connecting as battens, 2 x M10 nuts for additional fixings | |
| IP Rating | IP20 | |
| Colour | Black as standard, also available in Gold, Polished Mirror, Green, Red, Pewter, Champagne, Blue & Light Bronze at an extra cost | |
| Approvals | EN55103-1 & 2, IEC60950 | |
| No. of LED heads | 3 x RGBA single colour output cells, total 48 LEDs |
|---|---|
| Contol modes | HSI, RGBA, RGB (*Magic Amber), RGBI (Magic Amber) & stand-alone |
| Effects engine | Yes |
| Lumen output | Red 266 lumen, Green 445 lumen, Blue 56 lumen, Amber 242 lumen, White 532 lumen |
| Lamp life | L70 up to 50,000 hours |
| Optics | Specialised close focus lens with advanced beam spreading technology |
| Beam Angle | 25° approx. (optional beam kits available) |
| Beam distribution | Asymmetrical direct illumination |
| CCT | Adjustable 1000 - 10,000K |
| CRI | 90 |
| Colour gamut | Performance Enhanced |
Photometric Data for Colour White
| 3'/1m | 6'/2m | 9'/3m | 12'/4m | 15'/5m | |
| FC | 182 | 49 | 23 | 14 | 8 |
| Lux | 1960 | 526 | 246 | 146 | 88 |
Photometric Data for Colour Red
| 3'/1m | 6'/2m | 9'/3m | 12'/4m | 15'/5m | |
| FC | 86 | 23 | 11 | 6 | 4 |
| Lux | 930 | 247 | 115 | 68 | 41 |
Photometric Data for Colour Green
| 3'/1m | 6'/2m | 9'/3m | 12'/4m | 15'/5m | |
| FC | 152 | 42 | 19 | 11 | 7 |
| Lux | 1637 | 438 | 203 | 117 | 76 |
Photometric Data for Colour Blue
| 3'/1m | 6'/2m | 9'/3m | 12'/4m | 15'/5m | |
| FC | 18 | 5 | 2 | 1 | 1 |
| Lux | 192 | 51 | 24 | 14 | 9 |
Photometric Data for Colour Amber
| 3'/1m | 6'/2m | 9'/3m | 12'/4m | 15'/5m | |
| FC | 88 | 24 | 10 | 7 | 4 |
| Lux | 952 | 253 | 110 | 72 | 40 |
