Color Charge™
Please note this item was discontinued in August of 2014
The Chroma-Q® Color Charge™ LED fixture is a 600 lumen, battery powered, wireless DMX fixture which is ideal for any indoor temporary lighting application where wiring is a challenge or where install speed is critical, transforming a venue in minutes.
Key Features
- Battery powered LED fixture - no need for mains power
- Long battery life - NiMH battery lasts up to 30 hours
- Long product life - up to 1,000 battery recharges
- Wireless control and syncing between units - no cables
- Theatrical grade dimming
- 600 lumen output – extremely bright for a battery powered fixture
- RGBA - improved colour rendition and a wider colour range
- High CRI of 92
- Future proof - interchangeable head
Nickel-Metal Hydride Battery
The Color Charge™ fixture's environmentally friendly design includes a recyclable long life battery cell and an interchangeable LED head for upgrading in the future. The highly efficient nickel-metal hydride (NiMH) power cell delivers up to 30 hours usage from a single charge and provides up to 1,000 charges; approximately double the life of lead-acid batteries. The fixture also features a built-in mains charger that enables it to continue to be used whilst charging, and a gas gauge showing the percentage and hours usage remaining.
Wireless
The Color Charge™ features wireless DMX control and synching between units, allowing connection of up to 512 fixtures on a single network. With a wireless range of 150m in a crowded room and 250m with a clear line of site, the Color Charge™ is ideal for large indoor spaces. Also, the unit's wireless aerial folds away discreetly for convenient transportation.
Master/Slave
The plug and play fixture also features synchronised effects between units, slave modes allowing simple opposite a/b colour effects and a built-in stand-alone playback mode.
High Quality Light
Part of the new generation of Chroma-Q LED lighting models, the Color Charge™ utilises unique colour mixing and control management technologies providing a high quality light output.
The Chroma-Q® RGBA engine has been developed to deliver an incredible CRI of 92, for true colour balance across the spectrum and accurate tungsten white light emulation. The fixture utilises unique ColorSure™ technology for enhanced colour consistency across fixtures.
The Color Charge™ is extremely bright for a battery powered fixture, producing 600 lumens output. The unit also features smooth, theatrical grade dimming, making it suitable for a wide range of temporary entertainment and architectural lighting applications.
Practical
Featuring a quick focus click mechanism providing stepped beam angles, the remote head can be quickly and easily positioned. For discreet usage, the unit features a black body and optional Half Hat Snoot to hide the lens source from view.
The Color Charge™ can be floor mounted or hung from truss via ½" nutsert and safely secured in place via a built-in Kensington lock slot. For maximum practicality, the Color Charge™ can also be mains powered and controlled via wired DMX.
Product code | CHCCRGBA |
---|---|
Dimensions | 140mm x 230mm x 280mm / 5.5" x 9" x 11" |
Weight | 7.5kg / 16lbs |
Power (charging only) | 100-240V AC, 50-60Hz, 100W, IEC |
Control protocol | ANSI E1.1 DMX-512A, wireless W-DMX / XLR 5 pin in / through |
Cooling | Convection |
Construction | Black anodised aluminium extrusion |
Built-in hardware | ½" nutsert, Kensington lock slot |
IP rating | IP20 |
Approvals | CISPR 22 :2006/EN55022 :2006 CISPR 24 :1997/EN55024 :1998 ICES-003 :2004 & FCC Part 15 Subpart B: 2007, CSA C22. No. 166-M1983: R2008 UL 1573:2003; UL 8750 |
LEDs | 1 x RGBA cell, total 12 LEDs |
---|---|
Control modes | 5 channels St RGBI (*Magic Amber) 5 channels Fx HSI 3 channels RGB 4 channels RGBA 1 channel DMX Look Select Demo Stand-alone Master |
Dimming Curve | Theatrical |
Variable effects engine | Yes |
Lumen output | 600 hot lumen (preliminary) |
Optics | Specialised close focus lens |
Beam angle | 22° |
Beam distribution | Symmetrical direct illumination |
CCT | Adjustable 1,000-10,000K |
CRI | 92 |
Colour gamut | Performance enhanced |
Lamp life | L70 up to 50,000 hours |
