Color Charge Plus™
Please note this item was discontinued in February of 2016
The Chroma-Q® Color Charge Plus™ is a higher-output version of the original battery-powered, wireless DMX fixture. It is ideal for any temporary indoor lighting applications where wiring is a challenge or where install speed is critical, transforming a venue in minutes.
- 900 lumens output – super bright for a battery-powered fixture
- 50% more light output than original Color Charge
- Battery-powered LED fixture - no need for mains power
- Long battery life - NiMH battery lasts up to 30 hours
- High CRI of 92
- Long product life - up to 1,000 battery recharges
- Wireless control and syncing between units - no cables
- RGBA - improved colour rendition and a wider colour range
- Theatrical grade dimming
- Future proof - interchangeable head
50% More Lumen Output
The Color Charge Plus™ utilises the very latest generation of LED and optics, resulting in 50% more output (900 lumens) than the original Color Charge™ (600 lumens) from the same size unit.
Nickel-Metal Hydride Battery
The Color Charge Plus™ fixture's environmentally friendly design includes a recyclable long life battery cell and an interchangeable LED head for upgrading in the future. The highly efficient nickel-metal hydride (NiMH) power cell delivers up to 30 hours usage from a single charge and provides up to 1,000 charges; approximately double the life of lead-acid batteries. The fixture also features a built-in mains charger that enables it to continue to be used while charging, and a gas gauge showing the percentage and hours of usage remaining.
The Color Charge Plus™ features Wireless Solutions wireless DMX control and syncing between units, allowing connection of up to 170 fixtures on a single network. With a wireless range of 100m in a crowded room and 200m with a clear line of sight, the Color Charge Plus™ is ideal for large indoor spaces. Also, the unit's wireless aerial folds away discreetly for convenient transportation.
The plug and play fixture also features synchronised effects between units, slave modes allowing simple opposite a/b colour effects and a built-in stand-alone playback mode.
Part of the new generation of Chroma-Q® LED lighting models, the Color Charge Plus utilises unique colour mixing and control management technologies providing a high-quality light output.
The Chroma-Q® RGBA engine has been developed to deliver an incredible CRI of 92, for true colour balance across the spectrum and accurate tungsten white light emulation. The fixture utilises unique ColorSure™ technology for enhanced colour consistency across fixtures.
Theatrical Grade Dimming
The unit also features smooth, theatrical grade dimming, making it suitable for a wide range of temporary entertainment and architectural lighting applications.
Featuring a quick focus click mechanism providing stepped beam angles, the remote head can be quickly and easily positioned. For discreet usage, the unit features a black body and optional half hat snoot to hide the lens source from view.
The Color Charge Plus™ can be floor mounted or hung from truss via 1/2" nutsert and safely secured in place via a built-in Kensington lock slot. For maximum practicality, the Color Charge Plus™ can also be mains powered and controlled via wired DMX.
- Color Charge Plus™ Brochure (English)
- Color Charge Plus™ Spec Sheet
- Color Charge Plus™ User Manual
- Color Charge Plus™ Quick Start Guide
- Color Charge Plus™ Software
- Color Charge Plus™ Exploded Diagram
- Color Charge Plus™ IES
- Color Charge Plus™ CAD Symbol
- Color Charge Plus™ Declaration of Conformity
- Download All
|Dimensions||140mm x 230mm x 280mm / 5.5" x 9" x 11"|
|Weight||7.5kg / 16lbs|
|Shipping Dimensions||330mm x 304mm x 190mm / 13" x 12" x 7.5"|
|Shipping Weight||8kgs / 18lbs|
|Power (charging only)||100-240V AC, 50-60 Hz, 160VA|
|Power Consumption||77W @ 120V AC (Charging)|
|Power Connector In/Out||IEC|
|Data Connector In/Out||XLR 5-pin|
|Control Protocol||ANSI E1.11 USITT DMX 512-A, wireless W-DMX|
|Operating Temperature||0°C to 40°C|
|Construction||Anodised aluminum extrusion|
|Built-In Hardware||½" nutsert, Kensington lock slot|
|Approvals||CISPR 22 :2006/EN55022 :2006 CISPR 24 :1997/EN55024 :1998 ICES-003 :2004 & FCC Part 15 Subpart B: 2007, CSA C22. No. 166-M1983: R2008 UL 1573:2003; UL 8750|
|LEDs||1 x RGBA cell, total 12 LEDs|
|Control Modes||5 channels St RGBI (*Magic Amber)
5 channels Fx HSI
3 channels RGB
4 channels RGBA
1 channel DMX Look Select
|Variable Effects Engine||Yes|
|Effects Parameters||Colour speed, colour fan, colour range, colour step, intensity effects and intensity fan|
|Hot Lumen Output||900 (Red: 132, Green: 475, Blue: 46, Amber: 117)|
|Optics||Specialised close focus lens|
|Beam Angle||22° (Approx.)|
|Beam Distribution||Symmetrical direct illumination|
|Colour gamut||Performance enhanced|
|Lamp life||L70 at 50,000 hours|
