Color One 100™
The new Chroma-Q® Color One 100™ LED PAR features an innovative fully homogenised beam, virtually eliminating the colour separation and shadows synonymous with LED lighting - delivering above PAR performance from ONE source.
Utilising core LED technology from the Chroma-Q® premium performance lighting range, the multi-purpose fixture is ideal for a wide range of applications and provides a powerful, creative lighting tool.
This fixture is also available in daylight, tungsten and variable white versions.
- Fully homogenised beam
- RGBA colour-mixing palette
- Extremely uniform wash
- Defined 18° beam
- Bold saturates and subtle pastels from ONE source
- High CRI of 93
- Floor, truss or wall mountable
- Convection cooled for near-silent running
- Theatrical grade dimming
- Choice of IP20 and IP65 versions
Color One 100 Ordering Options
Smooth, Homogenised Optics
The Color One's custom optical design and fully homogenised output provides a smooth, uniform and defined 18° beam, with outstanding colour blend across the spectrum and no unsightly colour separation shadows.
This makes the Color One ideal for use as a front and backlight with clean shadows, and an uplighter with a smooth, even beam - all from ONE source.
Power Across The Spectrum
The Color One's huge RGBA colour-mixing palette delivers outstanding colour blend across the spectrum - including deep-cold blues, red-hot lava looks and super-soft pastels - as well as a complete range of whites - all from ONE source.
With RGBA colour mixing providing a high CRI of 93, the fixture can achieve extremely accurate colour matching.
Theatrical Grade Dimming
Theatrical grade dimming emulates the extremely smooth dimming curve of tungsten fixtures.
Multi-Purpose Workhorse Fixture
With the advanced feature set also including convection cooling for near-silent operation, a versatile mounting yoke and a choice of IP20 / IP65* models, the Color One 100 is suitable for numerous entertainment lighting applications - complementing the popular Chroma-Q® Color Force™ and Inspire™ LED fixtures ranges.
Convenient Remote-Controlled Operation
With a simple to use Infra-Red remote control included with each fixture, you can be up and running within minutes without the requirement of a lighting console - saving time and labour with instant access to preset colours, on/off, dimming and effects.
Compatible With Industry-Standard Accessories
To enable maximum flexibility with users' existing production inventory, the Color One accepts industry-standard 6.25" accessories such as egg crates, barndoors and top hats.
- Color One 100™ Brochure (English)
- Color One 100™ Spec Sheet
- Color One 100™ IP65 Spec Sheet
- Color One 10™0 IP65 Stainless Steel Spec Sheet
- Color One 100™ User Manual
- Color One 100™ Quick Start Guide V1.7
- Color One 100™ Software
- Color One I00™ IP65 and IP65SS Software
- Color One 100™ Exploded Diagram
- Color One 100™ IP65 Exploded Diagram
- Color One 100™ IP65 Stainless Steel Exploded Diagram
- Color One 100™ IES
- Color One 100™ IP65 IES
- Color One 100™ IP65 Stainless Steel IES
- Color One 100™ CAD Symbol
- Color One 100™ IP65 CAD Symbol
- Color One 100™ IP65 Stainless Steel CAD Symbol
- Color One 100™ Certificate of Conformity
- Color One 100™ Certificate of Origin
- Download All
|Product Code||CHCONE100RGBA (IP20)||CHCONE100RGBAIP (IP65)||CHCONE100RGBAIPSS (IP65)|
(Full Open Yoke)
|214mm x 267mm x 232mm / 8.5" x 10.5" x 9"|
|New Weight||3.8kg / 8.5lb||4.3kg / 9.5lb||4.3kg / 9.5lb|
|Shipping Dimensions||406mm x 228mm x 292mm / 16" x 9" x 11.5"|
|Shipping Weight||5.5kg / 12lb||6kg / 12.5lb||6kg / 12.5lb|
|Power Input Rating||100-240V AC 50-60Hz 125VA|
|Power Consumption||52W (Maximum); 5.5W (Stand-by)|
|Typical Power & Current||Measurements done with all LEDs at maximum intensity. Measurements made at nominal voltage. Allow for a deviation of +/- 10%.|
|Power Connectors In/Out||powerCON||Trailing lead||Trailing lead|
|Data Connectors In/Out||XLR 5-pin||Neutrik XLR 5-pin on 914mm/36" Tails In & Out||Neutrik Stainless Steel XLR 5-pin on 914mm/36" Tails In & Out|
|Control Protocol||ANSI E1.11 USITT DMX 512-A|
|Operating Temperature||0°C to 40°C||-20°C to +40°C||-20°C to +40°C|
|Construction||Cast machined aluminium|
|Colour||Black (custom colours available on request)|
|Built-In Hardware||Split Yoke, 6.25" Accessory Holder|
|Approvals||CISPR 15 / EN55015 & EN61547, FCC Part 15 Subpart B:2012 / ICES-003:2012, CSA C22.2, UL 1573, IEC 60598|
*As per IEC60529 ingress protection rating code.
|LEDs Per Engine||Combination of Red, Green, Blue and Amber|
|Control Modes||4 channels RGBA, 5 channels RGBAI, 3 channels HSI, 3 channels RGB, 3 channels MLED RGB, Master, Slave|
|Variable Effects Engine||Yes (via Wireless IR Remote)|
|Effects Parameters||Full Color Scroll, Warm Color Scroll, Cold Color Scroll and Fade In/Fade Out|
|Hot Lumen Output (Combined)||1,230|
|Beam Distribution||Symmetrical direct illumination|
|CCT||Adjustable 1,000 - 10,000K|
|Colour Gamut||Performance enhanced|
|Lamp Life||L70 at 50,000 hours|
