Color One 100X™
Reach NEW Heights of LED PAR Performance
The next generation of the Chroma-Q® Color One family is here: the Color One 100X™ LED PAR! This must-see luminaire features the same innovative homogenised beam as the Color One 100™, only with nearly 60% more output. The 100X's custom optical design and fully homogenised output delivers a powerful, smooth, uniform and defined 19° beam, with outstanding colour blending across the spectrum and no unsightly colour separation shadows. RGBA emitters deliver outstanding colours across the spectrum - including deep-cold blues, red-hot lava looks and super-soft pastels, as well as a complete range of whites ---all from ONE source.
Utilising core LED technology from the Chroma-Q® premium performance lighting range, the multi-purpose fixture is ideal for a wide range of applications and provides a powerful, creative lighting tool.
- Nearly 60% brighter than its predecessor
- Fully homogenised beam
- RGBA colour-mixing palette
- Extremely uniform wash
- Defined 19° beam
- Bold saturates and subtle pastels from ONE source
- High CRI of 93
- Floor, truss or wall mountable
- Quiet, convection cooled, no fans
- Theatrical grade dimming
- Chroma-Q calibration provides exceptional fixture-to-fixture consistency
Color One™ 100X Ordering Options
Smooth, Homogenised Optics
The Color One's custom optical design and fully homogenised output provides a smooth, uniform and defined 19° beam, with outstanding colour blend across the spectrum and no unsightly colour separation shadows.
This makes the Color One ideal for use as a front and backlight with clean shadows, and an uplighter with a smooth, even beam - all from ONE source.
Power Across The Spectrum
The Color One's huge RGBA colour-mixing palette delivers outstanding colour blend across the spectrum - including deep-cold blues, red-hot lava looks and super-soft pastels - as well as a complete range of whites - all from ONE source.
With RGBA colour mixing providing a high CRI of 93, the fixture can achieve extremely accurate colour matching.
Theatrical Grade Dimming
Theatrical grade dimming emulates the extremely smooth dimming curve of tungsten fixtures.
Multi-Purpose Workhorse Fixture
With the advanced feature set also including convection cooling for quiet operation, a versatile mounting yoke and a choice of IP20 / IP65* models, the Color One 100™ is suitable for numerous entertainment lighting applications - complementing the popular Chroma-Q® Color Force™ and Inspire™ LED fixtures ranges.
Convenient Remote-Controlled Operation
With a simple to use Infra-Red remote control included with each fixture, you can be up and running within minutes without the requirement of a lighting console - saving time and labour with instant access to preset colours, on/off, dimming and effects.
Compatible With Industry-Standard Accessories
To enable maximum flexibility with users' existing production inventory, the Color One accepts industry-standard 6.25" accessories such as egg crates, barndoors and top hats.
- Color One 100X™ Brochure (English)
- Color One 100X™ Brochure (Française)
- Color One 100X™ Spec Sheet
- Color One 100X™ IP65 Spec Sheet
- Color One 100X™ IP65 Architectural Specifications
- Color One 100X™ Architectural Specifications
- Color One 100X™ User Manual
- Color One 100X™ Quick Start Guide V1.7
- Color One 100X™ Software
- Color One 100X™ IP65 Software
- Color One 100X™ Exploded Diagram
- Color One 100X™ IP65 Exploded Diagram
- Color One 100X™ IES
- Color One 100X™ IP65 IES
- Color One 100X™ Photometric Table
- Color One 100X™ CAD Symbol
- Color One 100X™ IP65 CAD Symbol
- Color One 100X™ 2D Symbols DWG
- Color One 100X™ 3D Symbols DWG
- Chroma-Q VectorWorks Symbols
- Color One 100X™ Declaration of Conformity
- Color One 100X™ Declaration of Origin
- Download All
|Product Code||CHCONE100XRGBA (IP20)||CHCONE100XRGBAIPSS (IP65)|
(Full Open Yoke)
|214mm x 267mm x 232mm / 8.5" x 10.5" x 9"|
|New Weight||3.8kg / 8.5lb||4.3kg / 9.5lb|
|Shipping Dimensions||406mm x 228mm x 292mm / 16" x 9" x 11.5"|
|Shipping Weight||5.5kg / 12lb||6kg / 12.5lb|
|Power Input Rating||100-240V AC 50-60Hz 125VA|
|Power Consumption||63W (Maximum); 5.5W (Stand-by)|
|Typical Power & Current||Measurements done with all LEDs at maximum intensity. Measurements made at nominal voltage. Allow for a deviation of +/- 10%.|
|Power Connectors In/Out||powerCON||Trailing lead|
|Data Connectors In/Out||XLR 5-pin||Neutrik Stainless Steel XLR 5-pin on 914mm/36" Tails In & Out|
|Control Protocol||ANSI E1.11 USITT DMX 512-A|
|Operating Temperature||0°C to 40°C||-20°C to +40°C|
|Construction||Cast machined aluminium|
|Colour||Black (custom colours available on request)|
|Built-In Hardware||Split Yoke, 6.25" Accessory Holder|
|Approvals||CISPR 15 / EN55015 & EN61547, FCC Part 15 Subpart B:2012 / ICES-003:2012, CSA C22.2, UL 1573, IEC 60598|
|LEDs Per Engine||Combination of Red, Green, Blue and Amber|
|Control Modes||4 channels RGBA, 5 channels RGBAI, 3 channels HSI, 3 channels RGB, 3 channels MLED RGB, Master, Slave|
|Variable Effects Engine||Yes (via Wireless IR Remote)|
|Effects Parameters||Full Color Scroll, Warm Color Scroll, Cold Color Scroll and Fade In/Fade Out|
|Hot Lumen Output (Combined)||1,950|
|Beam Distribution||Symmetrical direct illumination|
|CCT||Adjustable 1,000 - 10,000K|
|Colour Gamut||Performance enhanced|
|Lamp Life||L70 at 50,000 hours|
- Wireless IR Remote (included)
- Diffusion Frame (included) - Does not work with the IP rated version
Color One 100X™ Narrow
Color One 100X™ Medium
