Studio Force V Compact™
Please note this item was discontinued in January of 2015
The Chroma-Q® Studio Force V Compact™ is a powerful 3,000K - 6,100K CCT, variable white lighting tool featuring laboratory calibrated 3200°K and 5600°K presets that works in perfect harmony with the popular Studio Force range. The Compact is a cost-effective workhorse, specifically designed for TV, film, touring, exhibitions, corporate events and theatre lighting applications. The fixture provides 2,600 lumens in a cost-effective, slim, compact profile.
- 3,000K - 6,100K CCT variable white
- Laboratory calibrated 3200°K and 5600°K presets
- Compact yet powerful - 2,600 lumens from a very small footprint
- IP65 rated
- Multi-purpose workhorse fixture - suitable for a wide range of applications
- Extremely smooth, uniform wash
- Theatrical grade dimming Ideal for TV, film, touring, exhibitions, corporate events and theatre
- Accepts City Theatrical accessories - use with your existing accessories
Compact Yet Powerful
Despite measuring only 212mm / 8.4" in length, the Studio Force V Compact™ produces an extreme output of 2,600 lumens – over 50% more white light output than its RGBA colour variant – making it ideal for lighting areas with a very small footprint.
Multi-Purpose Workhorse Fixture
With its rugged external design and IP65 rated casing, the Studio Force V Compact™ has been designed as a multi-purpose workhorse fixture suitable for numerous entertainment lighting applications - including uplighting, pipe-end shin-busting, backlighting, truss toner and other wash applications.
Fast & Efficient Set-Up
Up to five fixtures can be daisy-chained from each 15-way Compact PSU output, eliminating the need to home-run a cable from each fixture back to the PSU. In addition, up to four fixtures per output can be daisy-chained on a Chroma-Q® Color Block™ PSU (PSU-05B, PSU530).
The Studio Force V Compact™ enables an even wider range of users and budgets to utilise the power of the Studio Force as a creative lighting tool.
Optics & Dimming
The Studio Force V range's camera friendly custom optical design provides a smooth, uniform output, matched by theatrical grade dimming.
Full Range Of Accessories
For real versatility and compatibility with existing lighting inventories, the Studio Force V Compact™ is compatible with City Theatrical top hat, half top hat, egg crate louver and barn door accessories. The accessories also fit other models from the Force Compact range.
The fixture is supplied with a holder for these four optional accessories, as well as interchangeable clear and frosted glass light lenses.
An optional W-DMX wireless accessory for the 15-way PSU is also available.
Full Range Of Creative Tools
Complementing other models in the range, the Studio Force line-up now provides a full choice of creative tools for almost any entertainment application.
Daylight white and RGBA colour variants of each model are also available – see the Color Force range.
- Studio Force V Compact™ Brochure (English)
- Studio Force V Compact™ Spec Sheet
- Studio Force V Compact™ User Manual
- Studio Force V Compact™ Quick Start Guide
- Studio Force V Compact™ Exploded Diagram
- Studio Force V Compact™ IES
- Studio Force V Compact™ CAD Symbol
- Studio Force V Compact™ Declaration of Conformity
- Download All
|Dimensions**||212mm x 196mm x 152mm / 8.4" x 7.7" x 6"|
|Weight||4 kgs / 8.5 lbs|
|Shipping Dimensions||67mm x 254mm x 241mm / 10.5" x 10" x 9.5"|
|Shipping Weight||5.4kgs / 12 lbs|
|Power & Connections||Daisy-chained power & data connections|
|Power Supply||External - PSU15 | External - PSU5|
|Power Input Rating||48V DC|
|Typical Power & Current||Measurements done with all LEDs at max. intensity. Measurements made at nominal voltage. Allow for deviation of +/- 10%|
|Power Connector In/Out||XLR 4-pin|
|Data Connectors In/Out||XLR 4-pin|
|Max Cable Run||~60m / 200ft (PSU to last unit)|
|Control Protocol||ANSI E1.11 USITT DMX 512-A|
|Operating Temperature||0°C to 40°C|
|Construction||Cast machined aluminium|
|Built-In Hardware||Yoke assembly|
|Approvals||CISPR 22:2006/EN55022:2006 & CISPR 24:1997/EN55024:1998, ICES-003:2004, FCC Part 15 Subpart B:2010|
|LEDs Per Engine||14 Cold White / 14 Warm White|
|Control Modes (PSU15)||30 channels WW/CW
30 channels CTI
2 channels WW/CW
2 channels CTI
1 channel Look Select
|Variable Effects Engine||Yes|
|Effects Parameters||Intensity Effects|
|Hot Lumen Output (Combined)||2630 hot lumens @ 4300K|
|Optics||Specialised close focus lens|
|Beam Angle||14° (approx.)|
|Beam Angle with Optional Frosted Optic||21° (approx.)|
|Beam Distribution||Asymmetrical direct illumination|
|CCT||3,000K - 6,000K (+/- 200K)|
|Colour Gamut||Performance enhanced|
|CRI||~80 @ 4300K|
|Lamp Life||L70 at 50,000 hours|
