Color Span™
Create Your Own Custom LED Fixture
Please note this item was discontinued in January of 2011
The Chroma-Q® Color Span™ is a configurable low profile, ultra bright LED cove lighting and wall wash system for wide ranging applications. The fixture gives lighting designers, specifiers and end users the flexibility to specify many aspects of its design to meet their particular application needs.
Request A DemoKey Features
- Configure the IP rating, body length, body colour, LED colours (4 circuits) and optics
- Low profile LED cove lighting and wall wash system
- Ultra bright - 1500 lumens per 1.2m / 4ft
- Choice of 2, 6 & 18 way power supplies
- Smooth, linear dimming curve
- Optional RGBA *Magic Amber™ configuration
- Color Span Brochure
- Color Span Spec Sheet
- Color Span Manual
- Color Span Quick Start Guide
- Color Span 16-IP20 Exploded Diagram
- Color Span 16-IP67 Exploded Diagram
- Color Span 32-IP20 Exploded Diagram
- Color Span 32-IP67 Exploded Diagram
- Color Span 48-IP20 Exploded Diagram
- Color Span 48-IP67 Exploded Diagram
- Color Span CAD Symbol
- Download All
| 400mm / 16" | 800mm / 32" | 1200mm / 48" | |
| Dimensions - IP20 | 452mm x 79mm x 53mm / 17.8" x 3.1" x 2.1" | 859mm x 79mm x 53mm / 33.8" x 3.1" x 2.1" | 1259mm x 79mm x 53mm / 48.8" x 3.1" x 2.1" |
| Dimensions - IP67 | 456mm x 102mm x 62mm / 17.9" x 4" x 2.5" | 862mm x 102mm x 62mm / 33.9" x 4" x 2.5" | 1269mm x 102mm x 62mm / 49.9" x 4" x 2.5" |
| Weight - IP20 | 1.1 kgs / 2.5 lbs | 2 kgs. / 4.5 lbs. | 2.8 kgs. / 6.1 lbs. |
| Weight - IP67 | 3.2 kgs / 7 lbs | 4.7 kgs. / 10.4 lbs. | 6.3 kgs. / 13.8 lbs. |
| Shipping Dimensions | 584mm x 152mm x 114mm / 23" x 6" x 4.5" | 991mm x 152mm x 114mm / 39" x 6" x 4.5" | 1422mm x 152mm x 114mm / 56" x 6" x 4.5" |
| Colour | Black, White, Silver, Gold, Green, Red, Pewter, Champagne, Blue & Light Bronze | ||
| Built-In Hardware | Angle bracket for wall, ceiling & floor mounting | ||
| Approvals | Pending | ||
| 400mm / 16" | 800mm / 32" | 1200mm / 48" | |
| Total LEDs | 16 separate LEDs | 32 separate LEDs | 48 separate LEDs |
| Control Modes | See Color Span PS18, PS06 & PS02 | ||
| Dimming Curve | Theatrical | ||
| Variable Effects Engine | See Color Span PS18, PS06 & PS02 | ||
| Effects Parameters | See Color Span PS18, PS06 & PS02 | ||
| Hot Lumen Output (Combined) | 500 hot lumens (based on RGBA LED circuits) | 1,000 hot lumens (based on RGBA LED circuits) | 1,500 hot lumens (based on RGBA LED circuits) |
| Optics | Close focus lens with symmetrical direct illumination | ||
| Beam Angle | Narrow (12º), medium (23º) or wide (40º) (approx.) | ||
| CCT | Adjustable 1,000 - 10,000K | ||
| Colour Gamut | Performance enhanced | ||
| CRI | 82 | ||
| Lamp Life | L70 up to 50,000 hours | ||
